  UL AWM Style 1007
Application Internal wiring of electric and electronic equipment
Construction Conductor : 32 AWG ~ 16 AWG Solid or Stranded Wire
Insulation : PVC COMPOUND
Color Special color available upon request
Temperature Rating 80/90 ℃
Standard UL Subject 758
CSA C22.2 No. 210.2
Marking E203454 AWM 1007 VW-1 80℃ AWM I A FT1 90℃ 300V OOAWG KISEONG RoHS


Conductorr Insulation Max.
Conductor
Resistance
at 20℃		 Minimum
insulation
resistance
at 15.6℃

Voltage
in
Water
A.C

 Packing
Length
Type Gage Composition Outer
Diameter		 Thickness Outer
Diameter
  AWG ㎟ No./mm mm mm mm Ω/㎞ Ω/㎞ V/1min m(ft)
Stranded 30 0.05 7/0.102 0.31 0.42 1.15 381 15 2000 1220
(4000)
28 0.08 7/0.127 0.38 0.42 1.22 239 15 2000
26 0.14 7/0.160 0.48 0.42 1.32 150 15 2000
24 0.25 11/0.160 0.61 0.42 1.45 94.2 15 2000
22 0.34 17/0.160 0.76 0.42 1.60 59.4 15 2000 610
(2000)
20 0.50 26/0.160 0.94 0.42 1.78 37.4 15 2000
18 0.75 41/0.160 1.18 0.42 2.02 23.5 15 2000
16 1.50 26/0.254 1.49 0.42 2.33 14.6 15 2000
Solid 30 0.05 1/0.254 0.26 0.42 1.10 361 15 2000 1220
(4000)
28 0.08 1/0.320 0.32 0.42 1.16 227 15 2000
26 0.14 1/0.404 0.40 0.42 1.24 143 15 2000
24 0.25 1/0.511 0.51 0.42 1.35 89.3 15 2000
22 0.34 1/0.643 0.64 0.42 1.48 56.4 15 2000 610
(2000)
20 0.50 1/0.813 0.81 0.42 1.65 35.2 15 2000
18 0.75 1/1.02 1.02 0.42 1.86 22.2 15 2000
16 1.50 1/1.29 1.29 0.42 2.13 14.0 15 2000
